Pipes, directives and services are the parts of an Angular app that get reused the most, which makes them the parts where a missing test costs the most. They're also the parts where tests are cheapest to write, as long as you pick the right technique: a pure pipe is a function, a directive needs a host to live on, and a service that talks to a backend needs a fake backend you can control precisely.

This is lesson 11.4 of the Angular Tutorial. It follows lesson 11.3 on component tests with TestBed, and it refers back to pipes, directives and HttpClient from earlier modules. You'll learn how to unit test pure pipes, attribute and structural directives through small host components, services that use inject(), and HTTP code with provideHttpClientTesting() and HttpTestingController.

Matching the technique to the building block #

The pattern is the same throughout: test the public behaviour (what transform returns, what the host element looks like, what request goes out) rather than internals.

Pure pipes: test them as functions #

A pure pipe without dependencies is a class with one method. You don't need Angular to test it:

@Pipe({ name: 'initials' })
export class InitialsPipe implements PipeTransform {
  transform(name: string | null | undefined, max = 2): string {
    if (!name) return '';
    return name
      .trim()
      .split(/\s+/)
      .slice(0, max)
      .map(part => part[0]!.toUpperCase())
      .join('');
  }
}

import { describe, it, expect } from 'vitest';

describe('InitialsPipe', () => {
  const pipe = new InitialsPipe();

  it.each([
    ['Sam Rivera', 2, 'SR'],
    ['  maria   de la cruz ', 2, 'MD'],
    ['maria de la cruz', 3, 'MDL'],
    ['', 2, ''],
    [null, 2, ''],
  ])('initials(%j, %i) = %j', (input, max, expected) => {
    expect(pipe.transform(input, max)).toBe(expected);
  });
});

it.each is a good fit for pipes: one row per edge case keeps the test short and makes gaps obvious. Cover null and undefined explicitly, since template bindings pass them as soon as data is still loading.

If the pipe calls inject(), new throws because there's no injection context. Take a pipe that reads LOCALE_ID:

@Pipe({ name: 'localNumber' })
export class LocalNumberPipe implements PipeTransform {
  private locale = inject(LOCALE_ID);
  transform(value: number): string {
    return new Intl.NumberFormat(this.locale).format(value);
  }
}

Create it inside an injection context instead:

it('formats with the configured locale', () => {
  TestBed.configureTestingModule({ providers: [{ provide: LOCALE_ID, useValue: 'de-DE' }] });
  const pipe = TestBed.runInInjectionContext(() => new LocalNumberPipe());
  expect(pipe.transform(1500.5)).toBe('1.500,5');
});

Add one template-level test only if the pipe's behaviour depends on how it's used in a template, for example its interaction with async. Otherwise the function tests are enough.

Attribute directives: test through a host component #

A directive has no template of its own; its behaviour only exists on a host element. So create a small component in the spec that uses it the way your app does:

@Directive({
  selector: '[appHighlight]',
  host: { '[style.backgroundColor]': 'active() ? color() : null', '(mouseenter)': 'active.set(true)', '(mouseleave)': 'active.set(false)' },
})
export class Highlight {
  color = input('yellow', { alias: 'appHighlight' });
  protected active = signal(false);
}

@Component({
  imports: [Highlight],
  template: `
    <p appHighlight="lightblue">Custom</p>
    <p appHighlight>Default</p>
    <p>Plain</p>
  `,
})
class Host {}

describe('Highlight', () => {
  let fixture: ComponentFixture<Host>;
  let highlighted: DebugElement[];

  beforeEach(async () => {
    fixture = TestBed.createComponent(Host);
    await fixture.whenStable();
    highlighted = fixture.debugElement.queryAll(By.directive(Highlight));
  });

  it('applies to exactly the elements that use it', () => {
    expect(highlighted.length).toBe(2);
  });

  it('uses the bound colour on hover', async () => {
    const p = highlighted[0];
    p.triggerEventHandler('mouseenter');
    await fixture.whenStable();
    expect(p.nativeElement.style.backgroundColor).toBe('lightblue');

    p.triggerEventHandler('mouseleave');
    await fixture.whenStable();
    expect(p.nativeElement.style.backgroundColor).toBe('');
  });

  it('falls back to the default colour', async () => {
    highlighted[1].triggerEventHandler('mouseenter');
    await fixture.whenStable();
    expect(highlighted[1].nativeElement.style.backgroundColor).toBe('yellow');
  });
});

This is where DebugElement earns its place:

triggerEventHandler invokes the listeners Angular registered (template and host listeners). It doesn't dispatch a real DOM event, so it won't trigger native behaviour such as a form submit or a CSS :hover. When you need real browser behaviour, dispatch an event on nativeElement instead.

Structural directives: assert on what gets rendered #

A structural directive decides whether, or how many times, a template is stamped out. Test the rendered result for each input value:

@Directive({ selector: '[appIfRole]' })
export class IfRole {
  private tpl = inject<TemplateRef<unknown>>(TemplateRef);
  private vcr = inject(ViewContainerRef);
  private auth = inject(AuthStore);
  role = input.required<string>({ alias: 'appIfRole' });

  constructor() {
    effect(() => {
      this.vcr.clear();
      if (this.auth.roles().includes(this.role())) this.vcr.createEmbeddedView(this.tpl);
    });
  }
}

@Component({
  imports: [IfRole],
  template: `<button *appIfRole="'admin'" class="delete">Delete</button>`,
})
class Host {}

it('renders only for users with the role and reacts to changes', async () => {
  const roles = signal<string[]>(['viewer']);
  TestBed.configureTestingModule({ providers: [{ provide: AuthStore, useValue: { roles } }] });
  const fixture = TestBed.createComponent(Host);
  await fixture.whenStable();
  expect(fixture.nativeElement.querySelector('.delete')).toBeNull();

  roles.set(['viewer', 'admin']);
  await fixture.whenStable();
  expect(fixture.nativeElement.querySelector('.delete')).not.toBeNull();
});

Faking AuthStore with an object holding a real signal is a useful trick: you control the state directly, and the directive's effect reacts exactly as it would to the real store.

Services that use inject() #

A service that uses inject() can't be created with new outside an injection context, and that's fine: let TestBed build it, and replace its dependencies with providers:

@Injectable({ providedIn: 'root' })
export class Checkout {
  private cart = inject(CartStore);
  private payments = inject(PaymentGateway);

  async pay() {
    if (this.cart.isEmpty()) throw new Error('Cart is empty');
    return this.payments.charge(this.cart.total());
  }
}

describe('Checkout', () => {
  const charge = vi.fn(async (amount: number) => ({ ok: true, amount }));

  beforeEach(() => {
    charge.mockClear();
    TestBed.configureTestingModule({
      providers: [
        { provide: PaymentGateway, useValue: { charge } },
        { provide: CartStore, useValue: { isEmpty: signal(false), total: signal(42) } },
      ],
    });
  });

  it('charges the cart total', async () => {
    await expect(TestBed.inject(Checkout).pay()).resolves.toEqual({ ok: true, amount: 42 });
    expect(charge).toHaveBeenCalledOnce();
    expect(charge).toHaveBeenCalledWith(42);
  });
});

Fake only the boundaries (payment gateway, storage, the clock), and keep the real versions of simple collaborators when they're cheap. A test full of mocks verifies your mocks, not your code. TestBed resets between tests automatically, so each test gets fresh instances.

HTTP services with HttpTestingController #

For code that uses HttpClient, Angular replaces the real backend with a testing backend you control:

@Injectable({ providedIn: 'root' })
export class ProductsApi {
  private http = inject(HttpClient);
  search(q: string) {
    return this.http.get<Product[]>('/api/products', { params: { q } });
  }
}

import { provideHttpClient } from '@angular/common/http';
import { provideHttpClientTesting, HttpTestingController } from '@angular/common/http/testing';
import { firstValueFrom } from 'rxjs';

describe('ProductsApi', () => {
  let http: HttpTestingController;
  let api: ProductsApi;

  beforeEach(() => {
    TestBed.configureTestingModule({
      providers: [provideHttpClient(), provideHttpClientTesting()],   // order matters
    });
    http = TestBed.inject(HttpTestingController);
    api = TestBed.inject(ProductsApi);
  });

  afterEach(() => http.verify());   // fails if any request was not handled

  it('sends the query and returns the results', async () => {
    const result = firstValueFrom(api.search('lamp'));

    const req = http.expectOne(r => r.url === '/api/products');
    expect(req.request.method).toBe('GET');
    expect(req.request.params.get('q')).toBe('lamp');
    req.flush([{ id: 'p1', name: 'Desk lamp' }]);

    expect(await result).toEqual([{ id: 'p1', name: 'Desk lamp' }]);
  });

  it('surfaces server errors', async () => {
    const result = firstValueFrom(api.search('x'));
    http.expectOne(r => r.url === '/api/products').flush('Boom', { status: 500, statusText: 'Server Error' });
    await expect(result).rejects.toMatchObject({ status: 500 });
  });
});

The key points:

• Provide provideHttpClient() before provideHttpClientTesting(). The testing provider replaces the backend that the first one sets up; in the other order, tests break.
• Include your interceptors with provideHttpClient(withInterceptors([...])) when you want them under test, exactly as in app.config.ts.
• expectOne fails if zero or several requests match; use match() when several are expected and expectNone() to prove a request did not happen (useful for caching, see lesson 10.4).
• flush(body, { status, statusText }) simulates server responses, and req.error(new ProgressEvent('error')) simulates a network failure.
• verify() in afterEach catches unexpected extra requests, such as a duplicated call or a retry you didn't intend.

Because the request is only sent when someone subscribes, start the subscription (here with firstValueFrom) before calling expectOne.

Gotchas #

What's next #

Lesson 11.5 closes Module 11 by stepping outside unit tests: Playwright, Cypress and WebdriverIO for end-to-end testing, how ng e2e sets each one up, which tests belong in E2E and which belong in unit or component tests, and how to keep E2E suites fast and reliable in CI.

Try it yourself #

Pick one custom pipe and one HTTP service in your app. Give the pipe an it.each table that includes null, an empty string and one unusual input. For the service, write a test that flushes a 500 error and checks that the error reaches the caller in the shape your components expect.
